Hollow Core Fibers

Name: Hollow Core Fibers
SKU: TTF-NIR 1310-S
Availability: InStock

Hollow Core Fibers The TTF-NIR 1310-S hollow-core fiber exhibits transmission losses of less than 1 dB/km in the O-band. Combined with its 31% lower latency, it becomes an ideal choice for intra-datacenter optical transmission.

SKU: TTF-NIR 1310-S

0.000 (CNY)

Qty:


Product	TTF-NIR 1310-S
Parameters
Optimized for (nm)	1310
Material	air core
Core diameter (μm)	28±2
Attenuation (dB/km)	<1 @ 1310 nm
Transmission bandwidth (nm)	1150-1500
Mode field diameter(μm)	20±2
Dispersion (ps/nm/km)	<5 @ 1310 nm
Numerical aperture	0.03
HOM suppression (dB)	>30
Bend loss @ 5 cm radius (dB/50 turn)	<0.1
Calculated Dispersion (ps/nm/km)	Transmission Loss (dB/km)
